TCPDump deepdive for Linux engineers

As a SIEM platform administrator, one of the most invaluable tools in my troubleshooting arsenal is tcpdump. It allows the user to display TCP/IP and other packets being transmitted or received over a network. Despite its simplicity, it is incredibly powerful for debugging complex network issues, monitoring traffic, or simply learning how different protocols behave.

Why use tcpdump

• Real-time packet inspection
• Lightweight and scriptable
• No need for a GUI
• Useful for security auditing and troubleshooting

How to install tcpdump

On Debian/Ubuntu-based systems:

sudo apt update && sudo apt install tcpdump

On RHEL/CentOS (YUM-based systems):

sudo yum install tcpdump

On Fedora/DNF-based systems:

sudo dnf install tcpdump

From Source:

sudo apt install libpcap-dev gcc make -y
wget http://www.tcpdump.org/release/tcpdump-4.99.4.tar.gz
tar -xvzf tcpdump-4.99.4.tar.gz
cd tcpdump-4.99.4
./configure
make
sudo make install

Basic usage examples

Capture traffic on eth0

tcpdump -i eth0

Capture only TCP packets

tcpdump -i eth0 tcp

Capture packets from a specific host

tcpdump -i eth0 host 192.168.1.100

Save captured data to a file

tcpdump -i eth0 -w capture.pcap

Read from a saved capture file

tcpdump -r capture.pcap

Limit the number of packets

tcpdump -i eth0 -c 100

Filter by port

tcpdump -i eth0 port 443

Verbose output with hex

tcpdump -XX -i eth0

Display packet timestamp in readable format

tcpdump -tttt -i eth0

Real-World Example: Debugging HTTP Requests

tcpdump -i eth0 -nn -s 0 -v tcp port 80

This captures HTTP requests in verbose mode, disables hostname and port name resolution, and captures the entire packet.

Security consideration

You need elevated privileges to run tcpdump. Consider creating a dedicated group or using capabilities:

sudo setcap cap_net_raw,cap_net_admin=eip $(which tcpdump)

Important notice!

During troubleshooting, I encountered an issue on two occasions where no logs were received. Further investigation with tcpdump revealed insights into the packets that were received. When comparing incoming data, it was observed that the data had a length greater than zero, whereas the other log source only showed packets of length zero. After restarting the syslog service on the host that stopped sending data, new data was successfully ingested into our SIEM.

Please note that a packet length of zero can indicate two possibilities: the data might be encrypted, or, as in the example provided, the packets could be used to maintain the connection (keep-alive packets).

Conclusion

Whether you’re a network administrator, security professional, or developer, tcpdump is a skill worth mastering. Its ability to dissect network traffic at the most granular level makes it indispensable in any Linux environment.

Cheatsheet

A more extensive cheatsheet can be found here: TCPDump cheatsheet
